BAC Mono R Specs, Price, Features, Colors, Pictures & Reviews

The BAC Mono R is a track-focused single seater road legal sports car comes with a 2.5-liter, four-cylinder engine delivers an impressive 343 horsepower and 330 Nm of torque, propelling the car to exhilarating speeds. The 6-speed sequential transmission ensures lightning-fast gear changes, allowing drivers to fully exploit the car's performance potential.

Rate BAC Mono R:

3.6/5 (7 votes)

Write a Review

BAC Mono R Price £ 217000 [United Kingdom]

The price could differ based on factors such as color, accessories and other features.

Country, City	Retail Price	Total Price
United Kingdom	£ 217000	--

Picture Gallery

View More Pictures

Technical Specifications

Vehicle Type	Car
Fuel	Petrol
Engine Displacement	2488.00 cc
Engine Details	Normally Aspirated, 4 cylinder, in-line, semi-structurally mounted, In-line, cylinders
Bore x Stroke	89mm x 100mm
Engine Lubrication	Dry sump with internal scavenge pump
Clutch	AP Racing (sintered high performance), Intelligent launch control
Maximum Power	343 bhp
Maximum Torque	330 Nm
Transmission	6 speed sequential Ratios (standard): Final drive 9:31 1st = 12:38 2nd = 14:33 3rd = 15:27 4th = 18:25 5th = 24:27 6th = 24:24 Gear Selection: Pneumatic semi-automatic closed loop system operated via steering wheel mounted paddles Shiftec valve block Switchable auto upshift

Brakes
Front Brake	Surface Transforms Carbon Ceramic discs AP Racing, Formula Car Caliper - Radial 4 Piston
Rear Brake	Surface Transforms Carbon Ceramic discs AP Racing, Formula Car Caliper - Radial 4 Piston

Chassis and Suspension
Front Suspension	Adjustable pushrod activated twin wishbone system with needle roller bearing mounted bell cranks, rising rate, optimized camber change and roll centre position, full Ackermann geometry, shim adjustable camber Ultra light, billet aluminium uprights Two way adjustable Öhlins dampers
Rear Suspension	Gearbox mounted, Adjustable pushrod activated twin wishbone system with needle roller bearing mounted bell cranks, rising rate, optimized camber change and roll centre position, shim adjustable camber Ultra light, billet aluminium uprights Two way adjustable Öhlins dampers

Tyres
Wheels / Rim	Front: O.Z. Racing / BAC developed HRT alloy 7.5j x 17in Rear: O.Z. Racing / BAC developed HRT alloy 8.5j x 17in
Front Tyre	Bespoke Pirelli Trofeo R / BAC developed 205/45 R17
Rear Tyre	Bespoke Pirelli Trofeo R / BAC developed 255/40 R17

Dimensions
Length	4007 mm
Width	1836 mm
Height	1085 mm
Wheelbase	2565 mm
Weight	555 kg
Ground Clearance	95-f/115-r mm
Fuel Tank Capacity	35 litres

Additional Details
Power to weight: 613 bhp per tonne Weight distribution: 49% (f) / 51% (r) Camshafts: Performance inlet and exhaust camshafts and uprated valve springs Induction System: Gas flowed cylinder head with individual butterfly port throttles Intake System: F3 style BAC / K&N aero optimized carbon inlet, remote filtration system and carbon airbox Exhaust: BAC developed, 4 into 2 into 1 lightweight, titanium exhaust manifold and collectors centrally mounted exhaust system Engine Management: Specialized Control Systems Delta 880 Safety: Master Kill Switch, 6 stage traction control (+off), FIA compliant plumbed-in Lifeline Fire Extinguisher System Differential: Powerflow LSD

Additional Details

Power to weight: 613 bhp per tonne
Weight distribution: 49% (f) / 51% (r)
Camshafts: Performance inlet and exhaust camshafts and uprated valve springs
Induction System: Gas flowed cylinder head with individual butterfly port throttles
Intake System: F3 style BAC / K&N aero optimized carbon inlet, remote filtration system and carbon airbox
Exhaust: BAC developed, 4 into 2 into 1 lightweight, titanium exhaust manifold and collectors centrally mounted exhaust system
Engine Management: Specialized Control Systems Delta 880
Safety: Master Kill Switch, 6 stage traction control (+off), FIA compliant plumbed-in Lifeline Fire Extinguisher System
Differential: Powerflow LSD
